Components of JST-XH 2-6S Plug Cable

2024-01-12

The "JST-XH 2-6S Plug Cable" refers to a balance connector used in lithium polymer (LiPo) battery packs commonly used in radio-controlled (RC) hobby applications, including RC cars, airplanes, helicopters, and drones.

Here's a breakdown of the components and specifications:

1. JST-XH: This indicates the connector type and series. JST-XH connectors are commonly used in RC LiPo battery packs for balancing individual cells. They are known for their reliability and are widely adopted in the hobbyist community.

2. 2-6S: This part denotes the number of cells the balance connector is designed to handle. Each cell in a LiPo battery is approximately 3.7 volts, and "2-6S" means the connector is designed for battery packs with 2 to 6 cells. Therefore, it's suitable for battery packs ranging from 7.4 volts (2S) to 22.2 volts (6S).

3. Plug Cable: This refers to the cable or wiring attached to the JST-XH connector. It usually has multiple wires, each corresponding to an individual cell in the battery. The balance connector allows for monitoring and balancing the voltage of each cell during charging or discharging, ensuring the cells stay within a safe voltage range.

In practical terms, a JST-XH 2-6S Plug Cable would be used to connect a LiPo battery to a balance charger or a device that monitors the individual cell voltages. The specific plug type and cable configuration are essential to ensure compatibility with the battery and the charging or monitoring equipment.

When dealing with batteries, it's crucial to follow proper safety guidelines and use compatible connectors and charging equipment. Using the correct balance connector helps prevent overcharging or over-discharging of individual cells, promoting the overall health and longevity of the battery pack.
